Pro technical specifications
Drone
| Specs |
Value |
| Ingress protection |
IPX8 |
| Dimensions |
485 x 257 x 354 mm (LxWxH) |
| Weight in air |
8.6 kg (with saltwater ballast) |
| Construction |
ABS enclosures, Aluminium pressure enclosures, Polycarbonate (PC) windows |
| Buoyancy material |
HCP 30 Polymer Foam |
| Maximum rated depth |
1000 ft / 305 m |
| Forward speed at normal use |
1.5 m/s (3 knots) |
| Thrusters |
4 x 350 W |
| Run time at normal use |
Approx. 2 hours / 5 hours |
| Operating temperature |
-5 to +35 °C |
Camera
| Specs |
Value |
| Mechanical tilt |
-30° to +30° |
| Vertical field of view |
115° |
| Sensor |
CMOS, 1/3 inch |
| Max image size |
1920 x 1080 pixels |
| Shutter speed |
1/30 s – 1/8000 s |
| Picture max resolution |
2M (1920 x 1080) |
| Picture type |
JPEG |
| Video resolution |
FHD: 1920 x 1080 25/30 Fps, HD: 1280 x 720 25/30 Fps |
| Video type |
MP4 |
| Video storage bit-rate |
2 to 16 MBit/s |
| SD card |
64 GB |
LED lights
| Specs |
Value |
| Luminous flux |
3300 Lumen |
| Colour temperature |
5000 K |
| Colour rendering index (CRI) |
90 |
| Adjustable dimming |
Yes |
Smart Battery Pack
Standard Battery
| Specs |
Value |
| Nominal Voltage |
14.8 V |
| Nominal Capacity |
6500 mAh |
| Nominal Energy |
96.2 Wh |
| Operating temperature |
-5 to +35 °C |
| Charging temperature |
5 to 30 °C |
High Capacity Battery
| Specs |
Value |
| Nominal Voltage |
14.4 V |
| Nominal Capacity |
14750 mAh |
| Nominal Energy |
212.4Wh |
| Operating temperature |
-5 to +35 °C |
| Charging temperature |
5 to 30 °C |
Sensors
| Specs |
Value |
| IMU |
3 axis gyro & accelerometer & magnetometer |
| Depth sensor |
Resolution: 0.2 mbar |
| Depth sensor operating range |
0 to 30 bar |
| Temperature sensor |
+/-1 °C |
Tether
| Specs |
Value |
| Length |
75 m |
| Breaking strength |
100 kg |
| Number of cables |
1 twisted pair (copper) |
| Size |
26 AWG |
Controller
| Specs |
Value |
| Compatibility |
iOS or Android |
Surface Unit
| Specs |
Value |
| Ingress protection |
IP64 |
| Dimensions |
38 x 149 x 158 mm (LxWxH) |
| Operating frequency |
2.4 GHz / 5.8 GHz |
| Max Wi-Fi distance |
30 m |
| Battery |
19.48 Wh |
| Operating temperature |
0 to +35 °C |
| Transmitter power |
125 mW |
| Operating voltage |
5 - 8.4 V |
| Output, USB A |
5 V, 400 mA |
| Input, Micro USB |
5 V, 2.1 A |
| Charging temperature |
+10 to 35 °C |
| Antenna |
Dual-band 3dBi RP-SMA Male |
Charger
| Specs |
Value |
| Dimensions |
56 x 107 x 64 mm (LxWxH) |
| Operating temperature |
5 to 30 °C |
| Operating rel. humidity |
20% to 80% |
| Input |
19.5 V, 4 A |
| Output |
16.8 V, 2.5 A |
Power supply
| Specs |
Value |
| Input |
100 - 240 V, 3A, 50 - 60 Hz |
| Output |
19.5 V, 11.8 A |
| Operating temperature |
0 to 40 °C |
| Operating rel. humidity |
20% to 80% |
| Manufacturer |
FSP Group |
| Model |
FSP230-AJAN3 |
